• Tires, Front Two 11R22.5G Goodyear G661 HSA (496 rev/mile)
• Tires, Rear Four 11R22.5G Goodyear G661 HSA (496 rev/mile)
• Black Front Bumper w/2 Tow Hooks
• Black Side Windows Trim and Black Front Windshield Trim
• Black Door Handles
• Fixed Rear Window
• Light Tinted Glass
• Variable Intermittent Wipers
• Composite/Galvanized Steel Panels
• Front Splash Guards
• Side Steps
• Black Grille
• Hood Grille Mount
• Aero-Composite Halogen Headlamps
• Cab Clearance Lights

• Radio AM/FM Stereo w/Aux Audio Input Jack & Clock -inc: With two speakers
• Radio w/Clock
• Fixed Antenna

• 30/0/30 Fixed Driver & Fixed Passenger w/Consolette - Vinyl
• Vinyl Front Seats w/Carpet Back Material
• Fixed Driver Seat
• Fixed Passenger Seat
• Manual Tilt Steering Column
• Manual Rear Windows
• Front Cupholder
• Cruise Control w/Steering Wheel Controls
• Manual Air Conditioning
• Glove Box
• Full Cloth Headliner
• Urethane Gear Shift Knob
• Passenger Visor Vanity Mirror
• Partial Floor Console and 2 12V DC Power Outlets
• Delay Off Interior Lighting
• Rear Map Lights
• Full Vinyl/Rubber Floor Covering
• Instrument Panel Bin, Dashboard Storage, Driver And Passenger Door Bins
• Manual 1st Row Windows
• Trip Computer
• Analog Display
• 2 12V DC Power Outlets

• Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters

6.7L POWER STROKE V8 TURBO DIESEL - 300 HP, 700 LB-FT TORQUE @ 1800 RPM

• CARB clean idle label - may be removed if un-necessary

• Engine Block Heater, Phillips, 120 Volt/750 Watt
• Transmission Power Take-Off Provision w/LiveDrive Capability
• Wheels, Front 22.5x8.25 Polished Aluminum, 10-Hole
• Wheels, Rear 22.5x8.25 Polished Aluminum, 10-Hole
• Air Brakes - Straight Truck w/Traction Control
• Air Dryer, Bendix AD/IP w/Heater
• Trailer Air Brake Package
• Taper-Leaf Springs, Parabolic - 12,000 lb. Cap
• Front Stabilizer Bar
• Lube, Front Axle, EmGard 50W, Synthetic Oil
• 23,000 lb. Single Reduction - Locking
• Multi-Leaf Springs - 23,000 lb. Cap
• Shock Absorbers, Rear - Double Acting
• Lube, Rear Axle, EmGard 75W-90, Synthetic Oil
• 5.57 Axle Ratio
• Single Channel - Straight 'C' 14.18 SM, 120,000 PSI
• Bumper, Front - Full Width, Chrome Plated Steel
• Chrome Grille Surround
• Under Cab, Right Side Outlet, Switchback-Style
• 200 Amp Denso SC5 Heavy Duty Alternator
• Jump Start Stud - Remote Mounted
• Battery - Two 900 CCA, 1800 Total, Includes Steel Battery Box
• Roof Marker/Clearance Lights - Clear Lenses, 5 Lights (Replaces Standard Amber Lenses)
• Body Builder Wiring - To End of Frame
• Voltmeter
• 30/0/30 Fixed Driver & Fixed Passenger w/Consolette - Vinyl
• 60/40 Rear Bench Seat w/Flip-Up Cushion and Fold-Down Back
• Preferred Equipment Package 600A
• Appearance Group
• Power Equipment Group
• Radio: AM/FM Stereo w/Aux Audio Input Jack & Clock
• Exterior Appearance Group
• Mirrors, Dual - Rectangular, XL2020 - 96" Width
• Mirrors, Dual - Rectangular, XL2020 - 96" Width w/Chrome Cap
• Engine Exhaust Brake
• Four Body Builder Switches - Mounted in Center Instrument Panel
• Bumper, Front - Black, Full Width
• Painted Grille - Plastic
• Chromed Fender Badge
• Floor Covering - Black Vinyl
• Wheel Seals, Front - Oil lubricated, SKF ScotSeal PlusXL Seals
• Chrome Trimmed Air Registers w/Positive Shut-Off
• Tow Hooks, Front (2) - Frame-Mounted, Painted Black
• Lights - Roof Marker/Clearance - Amber Lenses, 5 Lights
• Intelligent Oil Life Monitor
• Manual Regen Initiation - Driver Interface in Message Center
• Wheel Seals, Rear - Oil lubricated, SKF ScotSeal PlusXL Seals
• Steering Wheel - Black PVC w/Integral Cruise Control Switches
• Steering Column - Tilt
• Air Conditioning
• Driver's Seat Mounted Armrest
• Dual rear wheels
• 2 Speakers
• Variably intermittent wipers
• Trip computer
• Tilt steering wheel
• Split folding rear seat
• Speed control
• Rear reading lights
• Power steering
• Passenger vanity mirror
• Passenger seat mounted armrest
• AM/FM radio
• ABS brakes
• Tachometer

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 1500
• Cold Cranking Amps @ 0° F (2nd): 1500
• Cold Cranking Amps @ 0° F (3rd): 1500
• Maximum Alternator Capacity (amps): 200
• Weight Information
• Curb Weight - Front (lbs): 6851
• Curb Weight - Rear (lbs): 3993
• Gross Combined Wt Rating (lbs): 50000
• Suspension
• Suspension Type - Front: Leaf
• Suspension Type - Rear: Leaf
• Spring Capacity - Front (lbs): 10000
• Spring Capacity - Rear (lbs): 21000
• Axle Type - Front: Non-Independent
• Axle Type - Rear: Rigid Axle
• Axle Capacity - Front (lbs): 10000
• Axle Capacity - Rear (lbs): 21000
• Brakes
• Brake ABS System: 4-Wheel
• Brake ABS System (Second Line): 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 15
• Rear Brake Rotor Diam x Thickness (in): 15
• Front Drum Diam x Width (in): 15
• Tires
• Front Tire Order Code: TCT
• Rear Tire Order Code: RCT
• Front Tire Size: 11.0R22.5 AS
• Rear Tire Size: 11.0R22.5 AS
• Front Tire Capacity (lbs): 12350
• Rear Tire Capacity (lbs): 23360
• Revolutions/Mile @ 45 mph - Front: 496
• Revolutions/Mile @ 45 mph - Rear: 496
• Wheels
• Front Wheel Size (in): 22.5 X 7.5
• Rear Wheel Size (in): 22.5 X 7.5
• Steering
• Steering Type: Re-Circulating Ball
• Turning Diameter - Wall to Wall (ft): 52.8
• Frame
• Sect Modulus Rails Only (in³): 15.14
• Frame RBM (N/A): 1,275,200
• Frame Strength (lbs): 80000
• Frame Thickness (in): 0
• Fuel Tank
• Fuel Tank Location: Left Front
• Aux Fuel Tank Location: Left Front
• Exterior Dimensions
• Wheelbase (in): 182
• Width, Max w/o mirrors (in): 96.7
• Height, Overall (in): 94.3
• Cab to Axle (in): 72
• Frame Width, Rear (in): 3.1
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.4
• Front Shoulder Room (in): 68
• Front Hip Room (in): 67.6
• Second Head Room (in): 40.8
• Second Leg Room (in): 42.1
• Second Shoulder Room (in): 68
• Second Hip Room (in): 67.6
• Summary
• Vehicle Name: Ford Super Duty F-750 Straight Frame
• Body Style: Crew Cab
